Monocrystalline Solar Panel 300W 310W 320W 330W Rigid glass solar panels are best suited for long-term fixed installation, such as home, commercial, grid-tied and off-grid solar systems. Model: TR-300M Weight: 18.0kg Solar cell: Mono 156mm Dimension: 1640*992*35mm
156/158mm Mono Series
60-CELL MONOCRYSTALLINE SOLAR MODULE
300-330W
Electrical Parameters at STC
| Module | TR-300M | TR-310M | TR-320M | TR-330M |
| Pmax/W | 300 | 310 | 320 | 330 |
| Solar Panel Efficiency | 18.44% | 19% | 19.67% | 20.28% |
| Voc/V | 32.2 | 33 | 33.6 | 34.2 |
| Isc/A | 9.32 | 9.39 | 9.52 | 12.98 |
| Pmp/V | 38.5 | 39.45 | 39.98 | 40.7 |
| Imp/A | 9.65 | 9.95 | 10.09 | 10.2 |
| Power Tolerance | 0 to +5W | |||
| STC: Irradiance 1000W/㎡、AM=1.5、Module temperature 25℃ | ||||
Application
300-330W monocrystalline solar panel is perfect for permanent outdoor use to provide free electricity in any grid-tie, hybrid or off-grid application (such as charging batteries in vehicles or boats, or powering an off-grid house or cabin, or working with a grid-tie / hybrid inverter to feed energy into the electrical grid).
Dimension
| Size ( L x W x H) | Cell Qty | Power Range | Weight |
| 1640mm×992mm×35mm | 60 (6x10)pcs | 300-330W | About 18kg±3% |
Warttanty
^ 10-years warranty for material and technology
^ 25-years linear power output warranty
Please contact us for complete product parameters and solar panel cost.
